Overview of all component providers

note

This page has been automatically translated and has not been reviewed in detail yet. Therefore, the translation might not be completely accurate.

As a kind of reference and explanation for the providers available in NeuroomNet, all providers currently available in NeuroomNet are listed in the following subsections with their setting options and explanations. In particular, the following important information is provided:

  • Classification: Classification of the provider into active and passive:
    • Active providers (components): Active providers correspond to active components, i.e. components that contact the NeuroomNet server on their own. After the first such contact, NeuroomNet places the component in the setup module (e.g. based on the MAC address of the component, which can be used to automatically recognize this component in the future, even if the IP address has now changed).
    • Passive providers (components): Passive providers correspond to passive components, i.e. which are usually created manually in the Setup module of the NeuroomNet server including contact information (such as the IP address of the component). The corresponding components usually do not connect independently to the NeuroomNet server.
  • Network / Communication: Describes how the provider's components can be configured in NeuroomNet with regard to accessibility in the network (especially affects passive components, because NeuroomNet needs to know how to reach the respective components).
  • Promotions: List of all provider-specific (NeuroomNet) promotions. The standard actions that each component has ("Enforce Warning Level" and "Reset Warning Level") are not included in this listing.
  • Events: List of all provider-specific (NeuroomNet) events. The standard event that every component has ("State has changed") is not included in this list.

Provider Heatmap (formerly Camera)​

With Provider Heatmap (formerly Camera), (hardware) cameras from the manufacturer Xovis are addressed via a proprietary protocol for counting incoming and outgoing people at entrances/exits.

  • Classification: Passive
  • Network / Communication: IP address
  • Actions: Reset Counters
  • Events: None; The cameras are currently only addressed (and polled) by the heatmap module in a proprietary manner.

Provider Digital Signage Player​

The Provider Digital Signage Player addresses software digital signage players from inSynergie, each of which is installed on a computer (Windows, Linux, Android) in the network. Communication takes place via a proprietary protocol from inSynergie. More detailed documentation: Module Digital Signage

  • Classification: Active
  • Network / Communication: -
  • Actions:
    • Activate playlist
    • Activate schedule
    • Change display parameters -End blackout
    • Refresh schedule
    • Start blackout
  • Events: Request to switch signage input source

Provider DMX​

Provider DMX addresses DMX devices that can be controlled via ArtNet or DMX.

  • Classification: Passive
  • Network / Communication: IP address
  • Actions:
    • WriteChannel
    • WriteChannels
  • Events: -

Provider email server​

With Provider Email Server, email servers are addressed via a specific protocol.

  • Classification: Passive
  • Network / Communication:
    • Server URI -Authorization
  • Actions:
    • Send to email
  • Events: -

Provider Exhibit​

Provider Exhibit addresses exhibit software on (usually exhibit) PCs that can be remotely controlled using inSynergie's exhibit API (instead of or in addition to control using the provider/software PC client). |.

  • Classification: Active
  • Network / Communication: VendorId (= unique identification of the exhibit)
  • Actions:
    • Log users on or off
    • Reboot the computer
    • Restart the Exhibit Software
    • Shut down the computer
  • Events:
    • Animation for RFID readers
    • Day of Birth changed
    • New gender selected
    • Preferred User Language changed
    • Status report

Provider KNX​

With Provider KNX, (hardware) devices (sockets or lights) are addressed via the KNX protocol.

  • Classification: Passive
  • Network / Communication:
    • Name of the component
    • KNX/IP interface / gateway (IP)
    • KNX address
    • Data point type
  • Actions:
    • Send Data to Actor
  • Events:
    • Data received from sensor

With Provider Master Link, isMasters are addressed via a proprietary interface from inSynergie.

  • Classification: Passive
  • Network / Communication: Proxy address (= URL of the isMaster)
  • Actions:
    • [User defined in isMaster Administration and isMaster]
  • Events:
    • [User defined in isMaster Administration and isMaster]

Provider Network​

With Provider Network, any device that can be controlled via TCP, UDP or Telnet and through character or byte sequences (via PRT) can be addressed.

  • Classification: Passive
  • Network / Communication:
    • IP address
    • TCP, UDP or Telnet
    • Translation rule set (PRT)
    • ID (not currently used; a unique character string should be entered here for possible future use)
  • Actions:
    • [as defined in the PRT]
  • Events:
    • [as defined in the PRT]

Provider PC client​

With Provider PC Client, PCs on which the PC Client software from inSynergie is installed are addressed.

  • Classification: Active
  • Network / Communication: MAC address
  • Actions:
    • Reboot
    • Wake On LAN
    • Disable all serial ports
    • Enable all serial ports -Power off
    • [and much more]
  • Events: -

With provider PJLINK, video projectors or screens are addressed via the PJLINK protocol.

  • Classification: Passive
  • Network / Communication: IP address
  • Actions: -Choose input
    • Get lamp hours
    • Get error state -Power off -Power On
    • Set mute
  • Events:
    • Current input line
    • Error states
    • Lamp hour information
    • Mute state
    • Power status

Provider RFID reader​

With Provider RFID Reader, (hardware) RFID readers IS-CC-RFID-2.0 from inSynergie are addressed via a proprietary protocol.

More detailed documentation: https://neuroom.net/rfid/

  • Classification: Active
  • Network / Communication: Mac address
  • Actions:
    • Active attraction
    • Deactivate Attraction
    • IDLE animation
    • Switch all LEDs off
    • Reboot and update to latest firmware
    • Restart RFID unit
  • Events:
    • RFID detected
    • RFID input changed
    • RFID lost

Provider Serial​

Provider Serial addresses devices that are connected via RS-232 cable to a PC configured using an IP address and can be controlled via character or byte sequences (via PRT).

  • Classification: Passive
  • Network / Communication:
    • IP address
    • Translation rule set (PRT)
    • ID (not currently used; a unique character string should be entered here for possible future use)
  • Actions:
    • [as defined in the PRT]
  • Events:
    • [as defined in the PRT]

Provider SNMP​

Provider SNMP addresses devices that can be controlled via an IP address using the SNMP protocol.

  • Classification: Passive

  • Network / Communication: IP address

  • Actions:

    • [as defined in the PRT]

  • Events:

    • [as defined in the PRT]

Provider Software API​

The Provider Software API addresses PCs or software that can be controlled remotely using a protocol developed by Synergie (the so-called Software API).

Via this software API, which represents a type of generalization of the Exhibit API, the NeuroomNet server can be dynamically informed about available actions and events on the respective PC or software and can be controlled remotely accordingly.

  • Classification: Passive
  • Network / Communication: IP address
  • Actions:
    • [defined via the software API]
  • Events:
    • [defined via the software API]
